Handy Lift For Smaller Deere Tractor
If you've got a mid-size chore or garden tractor, you'll like this mini-lift built by Don Moss, Tallula, Ill.
To make a lift to fit his Deere 870, Moss first built a Cat I quick coupler hitch. Then he took a portable hand-cranked hydraulic lift jack and mounted it vertically on the hitch to use as the lift mechan
..........
You must sign in, subscribe or renew to see the page.
You must sign in, subscribe or renew to see the flip-book
Handy Lift For Smaller Deere Tractor MISCELLANEOUS EQUIPMENT Forklifts 19-1-11 If you've got a mid-size chore or garden tractor, you'll like this mini-lift built by Don Moss, Tallula, Ill.
To make a lift to fit his Deere 870, Moss first built a Cat I quick coupler hitch. Then he took a portable hand-cranked hydraulic lift jack and mounted it vertically on the hitch to use as the lift mechanism for the lift arm, which he made out of 3 by 4-in. tube steel. He replaced the hand-cranked cylinder on the jack with a 2-in. dia., 16-in. long cylinder operated by tractor hydraulics.
Moss says the lift is ideal for intermediate lifting chores, like taking the straw chopper off his Deere combine.
Contact: FARM SHOW Followup, Don Moss, Rt. 1, Box 27, Tallula, Ill. 62688.
