Tractor Tire Bead Breaker
 ✖  |
Our tractor tire bead breaker works great. It consists of three short chains and two jack-ails. The top of the jackalls are bolted together. A chain attaches to the bolt holding them together and wraps around the opposite side of the tire. A chain is then placed around the foot of each jack and around the tire. Then we put a little pressure on the jacks and hammer the foot of the jacks under the edge of the rim. We weld a 1-in. strip on the edge of the jacks which is against the rim. Jack each jack alternately and with the aid of a duck-billed hammer most tires will come off easily. (Len Digney, Box 53, Raymore, Sask. S0A 3J0)
Click here to download page story appeared in.
Click here to read entire issue
Tractor Tire Bead Breaker MISCELLANEOUS EQUIPMENT Miscellaneous 15-1-34 Our tractor tire bead breaker works great. It consists of three short chains and two jack-ails. The top of the jackalls are bolted together. A chain attaches to the bolt holding them together and wraps around the opposite side of the tire. A chain is then placed around the foot of each jack and around the tire. Then we put a little pressure on the jacks and hammer the foot of the jacks under the edge of the rim. We weld a 1-in. strip on the edge of the jacks which is against the rim. Jack each jack alternately and with the aid of a duck-billed hammer most tires will come off easily. (Len Digney, Box 53, Raymore, Sask. SOA 3J0)
